Ventura HR series

Ventura HR

The HR series comprises maintenance-free stationary AGM batteries with high-rate discharge performance, a 12 V rating, power up to 557 W at a 15-minute discharge rate, and extended service life. These batteries are designed primarily for short discharge runtimes.

View in 360°
Ventura HR

No. 1 for compact UPS systems

Ventura HR batteries are ideal for small and medium UPS systems, telecommunications, power engineering, fire and security systems, and other applications requiring high power over short discharge periods. They deliver up to 40% more power than standard batteries during short discharges.

Features

View:
Type
Rated
voltage, V
Power, W/block15 min to 1.6 V/cell
Length, mm
±3 mm
Width, mm
±3 mm
Height including terminals, mm
±3 mm
Weight, kg
±3 %
Terminal type
Leaflet
HR 1221W
HR 1228W
HR 1234W
HR 1251W
HR 1290W
12
12
12
12
12
141
192
231
346
559
90
151
151
152
182
70
65
65
99
77
107
100
100
100
167
1.72
2.35
2.5
3.67
5.76
S63
S63
S63
S63
F5
  • Series HR
  • AGM
New model name

Battery HR 1221W

  • Rated voltage, V: 12
  • Rated capacity, Ah: 141
  • Service life, years: 10
  • Series HR
  • AGM
New model name

Battery HR 1228W

  • Rated voltage, V: 12
  • Rated capacity, Ah: 192
  • Service life, years: 10
  • Series HR
  • AGM
New model name

Battery HR 1234W

  • Rated voltage, V: 12
  • Rated capacity, Ah: 231
  • Service life, years: 10
  • Series HR
  • AGM
New model name

Battery HR 1251W

  • Rated voltage, V: 12
  • Rated capacity, Ah: 346
  • Service life, years: 10
  • Series HR
  • AGM
New model name

Battery HR 1290W

  • Rated voltage, V: 12
  • Rated capacity, Ah: 559
  • Service life, years: 10
New model name
Battery HR 1221W

Ventura HR sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 10
  • Rated capacity, Ah: 141
  • Voltage, V: 12
New model name
Battery HR 1228W

Ventura HR sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 10
  • Rated capacity, Ah: 192
  • Voltage, V: 12
New model name
Battery HR 1234W

Ventura HR sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 10
  • Rated capacity, Ah: 231
  • Voltage, V: 12
New model name
Battery HR 1251W

Ventura HR sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 10
  • Rated capacity, Ah: 346
  • Voltage, V: 12
New model name
Battery HR 1290W

Ventura HR sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 10
  • Rated capacity, Ah: 559
  • Voltage, V: 12
Compare models

Applications

Advantages

  • Outstanding power during short discharge runtimes
  • Improved conductivity and shorter charging time through carbon added to the negative plates using GFC technology
  • More specially designed high-rigidity plates support high-current discharge and greater reliability
  • Special additives in the active material reduce internal resistance
  • Impact-resistant ABS case
  • Low self-discharge allows up to 12 months of storage without recharging
