Ventura CL series

Ventura CL

The CL series is a range of long-life, maintenance-free stationary AGM batteries rated at 2 V with capacities up to 3,000 Ah.

View in 360°
Ventura CL

No. 1 for power distribution networks

Ventura CL batteries serve power engineering and telecommunications facilities, medium and high-power UPS systems, and other applications requiring high energy capacity, flexible system voltage, and long battery life.

Features

View:
Type
Rated
voltage, V
Capacity, AhC10 to 1.8 V/cell
Length, mm
±3 mm
Width, mm
±3 mm
Height including terminals, mm
±3 mm
Weight, kg
±3 %
Terminal type
Leaflet
CL 2-100
CL 2-150
CL 2-200
CL 2-250
CL 2-300
CL 2-400
CL 2-500
CL 2-600
CL 2-800
CL 2-1000
CL 2-1200
CL 2-1500
CL 2-2000
CL 2-2500
CL 2-3000
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
100
150
200
250
300
400
500
600
800
1000
1200
1500
2000
2500
3000
171
171
170
170
170
196
241
285
383
471
471
266
349
496
496
72
101
106
106
150
171
171
171
171
171
171
229
233
363
363
210
227
346
346
343
343
343
343
343
343
343
566
566
374
374
5,60
8,35
12,5
14,0
17,5
23,0
28,6
34,4
45,7
56,0
61,5
92,0
121,0
160,0
173,5
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
F8
  • Series CL
  • AGM

Battery CL 2-100

  • Rated voltage, V: 2
  • Rated capacity, Ah: 100
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-150

  • Rated voltage, V: 2
  • Rated capacity, Ah: 150
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-200

  • Rated voltage, V: 2
  • Rated capacity, Ah: 200
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-250

  • Rated voltage, V: 2
  • Rated capacity, Ah: 250
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-300

  • Rated voltage, V: 2
  • Rated capacity, Ah: 300
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-400

  • Rated voltage, V: 2
  • Rated capacity, Ah: 400
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-500

  • Rated voltage, V: 2
  • Rated capacity, Ah: 500
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-600

  • Rated voltage, V: 2
  • Rated capacity, Ah: 600
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-800

  • Rated voltage, V: 2
  • Rated capacity, Ah: 800
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-1000

  • Rated voltage, V: 2
  • Rated capacity, Ah: 1000
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-1200

  • Rated voltage, V: 2
  • Rated capacity, Ah: 1200
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-1500

  • Rated voltage, V: 2
  • Rated capacity, Ah: 1500
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-2000

  • Rated voltage, V: 2
  • Rated capacity, Ah: 2000
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-2500

  • Rated voltage, V: 2
  • Rated capacity, Ah: 2500
  • Service life, years: 20
  • Series CL
  • AGM

Battery CL 2-3000

  • Rated voltage, V: 2
  • Rated capacity, Ah: 3000
  • Service life, years: 20
Battery CL 2-100

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 100
  • Voltage, V: 2
Battery CL 2-150

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 150
  • Voltage, V: 2
Battery CL 2-200

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 200
  • Voltage, V: 2
Battery CL 2-250

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 250
  • Voltage, V: 2
Battery CL 2-300

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 300
  • Voltage, V: 2
Battery CL 2-400

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 400
  • Voltage, V: 2
Battery CL 2-500

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 500
  • Voltage, V: 2
Battery CL 2-600

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 600
  • Voltage, V: 2
Battery CL 2-800

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 800
  • Voltage, V: 2
Battery CL 2-1000

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 1000
  • Voltage, V: 2
Battery CL 2-1200

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 1200
  • Voltage, V: 2
Battery CL 2-1500

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 1500
  • Voltage, V: 2
Battery CL 2-2000

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 2000
  • Voltage, V: 2
Battery CL 2-2500

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 2500
  • Voltage, V: 2
Battery CL 2-3000

Ventura CL sealed lead-acid batteries use AGM technology, with liquid electrolyte absorbed in a fiberglass separator.

  • Technology: AGM
  • Service life, years: 20
  • Rated capacity, Ah: 3000
  • Voltage, V: 2
Compare models

Applications

Advantages

  • A broad model range and 2 V cell format support solutions across a wide power range
  • CL cell systems offer greater reliability: the load remains powered if one 2 V cell fails
  • Thicker plate grids made from high-purity lead alloy provide long service life and increased corrosion resistance
  • Improved conductivity and shorter charging time through carbon added to the negative plates using GFC technology
  • An organic substance added to the positive electrodes provides additional protection against active-material shedding through SOI technology
  • Impact-resistant ABS case
  • Low self-discharge allows up to 12 months of storage without recharging
