Ventura FFT series

Ventura FFT

Ventura FFT batteries use proprietary La Grande Forza di Carbonio technology, which adds carbon to the negative-plate active material to improve conductivity, charge acceptance, and cycle performance.

View in 360°
Ventura FFT

No. 1 for lifting equipment

Ventura FFT (Flooded Flat Traction)are flooded traction monoblocs with flat pasted plates. Low internal resistance supports faster charging and rapid attainment of rated capacity, while providing competitive cost and at least 1,000 charge-discharge cycles.

Ventura FTT (Flooded Tubular Traction)are flooded traction monoblocs with tubular plates. Designed for demanding conditions, they provide at least 1,200 charge-discharge cycles. FTT batteries combine low self-discharge during storage with a robust design for severe and extreme operating conditions.

Features

View:
Type
Rated
voltage, V
Capacity, AhC5 to 1.7 V/cell
Length, mm
±3 mm
Width, mm
±3 mm
Height including terminals, mm
±3 mm
Weight, kg
±3 %
Terminal type
Leaflet
FFT 06 185 Dual
FFT 06 197
FTT 06 180
FTT 06 210
FFT 06 270
FFT 06 295
FFT 06 320
FFT 08 145
FFT 12 060
FFT 12 080
FFT 12 105
FFT 12 110
FFT 12 120
FFT 12 150
FTT 12 120 DIN
6
6
6
6
6
6
6
8
12
12
12
12
12
12
12
185
197
180
210
270
295
320
145
60
80
105
110
120
150
120
263
263
244
244
311
311
308
261
278
312
344
344
329
512
344
181
181
190
190
181
181
174
181
175
175
172
172
181
223
172
281
281
281
281
358
358
416
274
190
212
234
284
274
220
284
30,5
32.2
31.5
32.4
47.6
50
48
30.8
19.2
23.3
26.5
31.8
39
43.3
37.5
Dual
Dual
A
A
UTL
UTL
Dual
UTL
A
A
A
A
UTL
A
A
  • Series FFT
  • FLA

Battery FFT 06 185 Dual

  • Rated voltage, V: 6
  • Rated capacity, Ah: 185
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 06 197

  • Rated voltage, V: 6
  • Rated capacity, Ah: 197
  • Cycle life: 1000
  • Series FTT
  • FLA

Battery FTT 06 180

  • Rated voltage, V: 6
  • Rated capacity, Ah: 180
  • Cycle life: 1200
  • Series FTT
  • FLA

Battery FTT 06 210

  • Rated voltage, V: 6
  • Rated capacity, Ah: 210
  • Cycle life: 1200
  • Series FFT
  • FLA

Battery FFT 06 270

  • Rated voltage, V: 6
  • Rated capacity, Ah: 270
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 06 295

  • Rated voltage, V: 6
  • Rated capacity, Ah: 295
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 06 320

  • Rated voltage, V: 6
  • Rated capacity, Ah: 320
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 08 145

  • Rated voltage, V: 8
  • Rated capacity, Ah: 145
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 060

  • Rated voltage, V: 12
  • Rated capacity, Ah: 60
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 080

  • Rated voltage, V: 12
  • Rated capacity, Ah: 80
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 105

  • Rated voltage, V: 12
  • Rated capacity, Ah: 105
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 110

  • Rated voltage, V: 12
  • Rated capacity, Ah: 110
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 120

  • Rated voltage, V: 12
  • Rated capacity, Ah: 120
  • Cycle life: 1000
  • Series FFT
  • FLA

Battery FFT 12 150

  • Rated voltage, V: 12
  • Rated capacity, Ah: 150
  • Cycle life: 1000
  • Series FTT
  • FLA

Battery FTT 12 120 DIN

  • Rated voltage, V: 12
  • Rated capacity, Ah: 120
  • Cycle life: 1200
Battery FFT 06 185 Dual

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 185
  • Voltage, V: 6
Battery FFT 06 197

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 197
  • Voltage, V: 6
Battery FTT 06 180

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,200 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1200
  • Rated capacity, Ah: 180
  • Voltage, V: 6
Battery FTT 06 210

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,200 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1200
  • Rated capacity, Ah: 210
  • Voltage, V: 6
Battery FFT 06 270

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 270
  • Voltage, V: 6
Battery FFT 06 295

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 295
  • Voltage, V: 6
Battery FFT 06 320

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 320
  • Voltage, V: 6
Battery FFT 08 145

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 145
  • Voltage, V: 8
Battery FFT 12 060

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 60
  • Voltage, V: 12
Battery FFT 12 080

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 80
  • Voltage, V: 12
Battery FFT 12 105

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 105
  • Voltage, V: 12
Battery FFT 12 110

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 110
  • Voltage, V: 12
Battery FFT 12 120

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 120
  • Voltage, V: 12
Battery FFT 12 150

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,000 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1000
  • Rated capacity, Ah: 150
  • Voltage, V: 12
Battery FTT 12 120 DIN

Ventura FFT traction lead-acid batteries use flooded lead-acid technology. They provide up to 1,200 cycles at 60% depth of discharge and can operate under extreme conditions.

  • Technology: FLA
  • Cycle life: 1200
  • Rated capacity, Ah: 120
  • Voltage, V: 12
Compare models

Applications

Advantages

  • Special low-resistance plate-grid alloy for fast charging
  • Special active-material formulation and plate design
  • Designed for intensive cycle operation
  • Up to 1,000–1,200 cycles at 60% depth of discharge
  • Designed for lifts, golf carts, electric vehicles, and other electric-powered equipment
  • Each battery individually shrink-wrapped
  • Durable Molded-In battery terminals
  • Fastener kit included with every block
